Section 2 Setup
2-6
9 11 1210
Fig. 2-1-2-3 Front panel (3)
9. Serial Bus 1 Serial bus connector 1
Currently not available.
10. Serial Bus 2 Serial bus connector 2
Currently not available.
11. Handset 2 Handset connector 2
Currently not available.
12. Handset 1 Handset connector 1
Handset connector (RJ11) used for a voice communication test on Phone 1.
To use this connector, the voice codec and audio board options are required.
