2.1 Part Names and Functions
2-7
13 14 15 16
Fig. 2-1-2-4 Front panel (4) – AF connector
AF connectors
13. AF2 Input AF2 input connector
Currently not available.
14. AF2 Output AF2 output connector
Currently not available.
15. AF1 Input AF1 input connector
A BNC input connector used for AF measurement on Phone 1. The voice
codec and audio board options are required.
16. AF1 Output AF1 output connector
A BNC output connector used for AF measurement on Phone 1. The voice
codec and audio board options are required.
CAUTION
Do not feed power exceeding the maximum permissible
power specified on the label or in the specification to the AF
input connector. Do not feed signals to the AF output
connector. Such attempts may damage the internal
circuits thus causing a fire accident or failure.
