Section 2 Setup
2-12
38 39 40 41 42
43
44
Fig. 2-1-2-9 Front panel (9)
Utility key
38.
Recall
Recall key
Starts reading parameter files.
Shift
+
Recall
Save Save key
Starts saving of parameter files.
39.
std
Standard key
Starts change of the system.
40.
Config
Configuration key
Opens the Configuration menu.
Cursor operation/data entry keys (Cursor/Data Entry)
41.
∧ ∨ < >
Cursor keys
Moves cursor or enters parameters.
42. Encoder
Turning this knob moves cursor or enters parameters. Pressing this knob starts
entering or determines the parameters.
43.
Set
Set key
Starts entering or determines the entered parameters.
44.
Cancel
Cancel key
Cancels the current input value and returns the previous settings.
