Section 2 Setup
2-30
MN8110A I/O adapter is available separately as an application part for the call proc-
essing port.
MN8110A is a unit that converts DSUB 15-pin connector into a BNC connector.
Connect the Call Proc. I/O connector (DSUB 15-pin) on the rear panel to that on
MT8820A using the connection cable provided with MN8110A. This allows in-
put/output of the MT8820A Call Proc. I/O connector input/output signal with the
BNC connector.
Front panel
Rear panel
Fig. 2-3-10-1 External view of MN8110A
