ARM ARM7TDMI - Page 194

AC and DC Parameters
7-22 Copyright © 2001, 2004 ARM Limited. All rights reserved. ARM DDI 0210C
T
cph
CPA,CPB hold time from MCLKr Minimum Figure 7-10 on page 7-10
T
cpi
MCLKf to nCPI valid Maximum Figure 7-10 on page 7-10
T
cpih
nCPI hold time from MCLKf Minimum Figure 7-10 on page 7-10
T
cpms
CPA, CPB to nMREQ, SEQ Maximum Figure 7-10 on page 7-10
T
cps
CPA, CPB setup to MCLKr Minimum Figure 7-10 on page 7-10
T
ctdel
TCK to ECLK delay Maximum Figure 7-16 on page 7-14
T
cth
Config hold time Minimum Figure 7-9 on page 7-9
T
cts
Config setup time Minimum Figure 7-9 on page 7-9
T
dbe
Data bus enable time from DBEr Maximum Figure 7-5 on page 7-7
T
dbgd
MCLKr to DBGACK valid Maximum Figure 7-13 on page 7-12
T
dbgh
DGBACK hold time from MCLKr Minimum Figure 7-13 on page 7-12
T
dbgrq
DBGRQ to DBGRQI valid Maximum Figure 7-13 on page 7-12
T
dbnen
DBE to nENOUT valid Maximum Figure 7-5 on page 7-7
T
dbz
Data bus disable time from DBEf Maximum Figure 7-5 on page 7-7
T
dckf
DCLK induced, TCKf to various outputs valid Maximum -
T
dckfh
DCLK induced, various outputs hold from TCKf Minimum -
T
dckr
DCLK induced, TCKr to various outputs valid Maximum -
T
dckrh
DCLK induced, various outputs hold from TCKr Minimum -
T
dih
DIN[31:0] hold time from MCLKf Minimum Figure 7-4 on page 7-6
T
dihu
DIN[31:0] hold time from MCLKf Minimum Figure 7-8 on page 7-9
T
dis
DIN[31:0] setup time to MCLKf Minimum Figure 7-4 on page 7-6
T
disu
DIN[31:0] set up time to MCLKf Minimum Figure 7-8 on page 7-9
T
doh
DOUT[31:0] hold from MCLKf Minimum Figure 7-3 on
page 7-5Figure 7-5 on
page 7-7
Table 7-23 AC timing parameters used in this chapter (continued)
Symbol Parameter
Parameter
type
Figure cross
reference
