ARM ARM7TDMI - Page 247

Debug in Depth
ARM DDI 0210C Copyright © 2001, 2004 ARM Limited. All rights reserved. B-37
45 nFIQ Input
46 nIRQ Input
47 nRESET Input
48 ISYNC Input
49 ABORT Input
50 nOPC Output
51 nCPI Output
52 nMREQ Output
53 SEQ Output
54 nTRANS Output
55 nM[4] Output
56 nM[3] Output
57 nM[2] Output
58 nM[1] Output
59 nM[0] Output
60 nEXEC Output
61 INSTRVALID Output
62 ALE Input
63 ABE Input
64 APE Input
65 TBIT Output
66 nWAIT Input
67 A[31] Output
68 A[30] Output
69 A[29] Output
Table B-3 Scan chain 0 cells (continued)
Number Signal Type
