Debug in Depth
B-38 Copyright © 2001, 2004 ARM Limited. All rights reserved. ARM DDI 0210C
70 A[28] Output
71 A[27] Output
72 A[26] Output
73 A[25] Output
74 A[24] Output
75 A[23] Output
76 A[22] Output
77 A[21] Output
78 A[20] Output
79 A[19] Output
80 A[18] Output
81 A[17] Output
82 A[16] Output
83 A[15] Output
84 A[14] Output
85 A[13] Output
86 A[12] Output
87 A[11] Output
88 A[10] Output
89 A[9] Output
90 A[8] Output
91 A[7] Output
92 A[6] Output
93 A[5] Output
94 A[4] Output
Table B-3 Scan chain 0 cells (continued)
Number Signal Type
