92
--- HDMI ARC (HDMI-1) ---
AudioType : Linear PCM
CH
1
2
ChannelStatusBit
04h 05h 00h 0Ah 0Bh
04h 05h 00h 0Ah 0Bh
Volume
7FFFFFh
7FFFFFh
SampleFreq : 96kHz
ARC RX is Inactive.
--- HDMI CEC Monitor --- VG Logical Address = 1h
RX:
TX:
RX:
01:a C3:a [EOM]
10 C0
01:a C1:a [EOM]
1
3
2
4
5
6
7
A B C
On the Audio Return Channel screen, the Audio data is displayed in the top part of the screen and the CEC
send/receive data is displayed in the bottom part of the screen.
Only the Audio data is displayed when Audio Monitor (1) has been selected as the Mode setting.
<List of Audio data display area items>
Status display The execution status of the generator’s ARC function is displayed here.
ARC RX is Inactive. The ARC receive function has not been executed.
(1)
ARC RX is Active. The ARC receive function has been executed.
(2) AudioType The type of audio is displayed here.
(3) SampleFreq The sampling frequency is displayed here.
(4) ChannelStatusBit The channel statuses are displayed here.
(5) Volume The volume (peak) levels are displayed here. (Linear PCM only)
* When Use CEC (0) has been selected as the Mode setting, the Audio data will not be displayed unless the
CEC command has been communicated properly.
<List of CEC data display area items>
(6) VG Logical Address The logical address of the generator is displayed here.
CEC send/receive data
The CEC command data sent from the generator or other devices is
displayed here.
(A) RX/TX
RX: These are the commands which have been received by the generator;
TX: these are the commands which the generator has sent.
(B) Data area The block data is displayed here (00 to FF).
(7)
(C) ACK area
The ACK data of the block is displayed here. (a: ACK present, n: ACK not
present)
* Only the commands received are displayed.
The following information is displayed in [ ] for (7):
[E_BUS]
When an attempt was made to send a command from the generator, the bus was not released so the
command would not be sent.
[E_ACK] ACK was not present in the command sent from the generator.
[E_ARB]
When a command was sent from the generator, another command came into conflict, and the
transmission was not completed.
[EOM] EOM of the block has been set.
* This is displayed only for commands which have been received.
