ASTRO VG Series User Manual

Chapter 6 PATTERN SETTINGS
369
6.13.8 Image pattern list
When the image list display is selected by pressing the NAME/LIST key while the generator output is
connected to the display, the information on the image patterns registered in the internal memory or on
the CF card is shown on the display.
If the CF card has been inserted, the information on the CF card is displayed; otherwise, the information
in the internal memory is displayed.
NO.: Image number
H, V-SIZE: Image size (width [dots], height [dots])
COLOR: Number of bits per dot
NAME: Image name
LICENSE: - No license required (standard)
available The license has been registered so the image list can be used. (option)
missing The license has not been registered so the image list cannot be used by this
generator. (option)
If the total number of pages exceeds 2, the pages can be selected using
/ .
6.13.9 OPT-USER pattern list
When the OPT-USER pattern list display is selected by pressing the NAME/LIST key while the
generator output is connected to the display, the names and sizes of the user optional patterns
registered in the internal memory or on the CF card are shown on the display.
If the CF card has been inserted, the names and sizes of the patterns on the CF card are displayed;
otherwise, the names and sizes of the patterns in the internal memory are displayed.
NO.: Pattern number
SIZE: Pattern size [bytes]
NAME: Pattern name
If the total number of pages exceeds 2, the pages can be selected using
/ .
Internal memory or CF card
Image Data List ( Internal:12345KB
f
ree ) ... 1/1
NO. H,V-SIZE COLOR NAME LICENSE
────────────────────────────────────
1 ( 1024, 768) 24bit owl -
101 ( 712, 484) 24bit china Monoscope available
102 ( 1920, 1080) 24bit carnation girl missing
:
:
:
Free space [KB]
Page number/total number of pages
USER OPT Data List ( Internal:12345KB
f
ree ) ... 1/1
NO. SIZE NAME
───────────────────
1 578 RGBW Color Bar
100 676 10Step & 1/10MHz
200 2549 DisplayPositionAdj
:
:
:
Free space [KB]
Internal memory or CF card
Page number/total number of pages
