ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
109
4.3.4 DVI data transfer systems
<Specifications with 8-bit output>
[Single (8 bit)]
The same images are output to all channels 1 and 2. The output level is 8 bits.
Given here as an example for explanatory purposes is a case where the resolution is 1280 × 1024, the dot clock
frequency is 108 MHz with 8 bits level.
D 0
[7：0]
D 1 D 2 D 3
・・・
・・・
[7：0] [7：0] [7：0]
D 1276
[7：0]
D 1277 D 1278 D 1279
[7：0] [7：0] [7：0]
CLK
108MHz
D 0
[Non]
D 1 D 2 D 3
・・・
D 1276 D 1277 D 1278 D 1279
1ch
Master
1ch
Slave
[Non] [Non] [Non] [Non] [Non] [Non] [Non]
D 0
[7：0]
D 1 D 2 D 3
・・・
[7：0] [7：0] [7：0]
D 1276
[7：0]
D 1277 D 1278 D 1279
[7：0] [7：0] [7：0]
2ch
1CH Master 2CH
