Chapter 11 SPECIFICATIONS
531
11.3.5 Tables of standard signals
 Table of TV standard signals (1 of 2)
Signal format
Total no. of
samples
Total no. of
samples
Total no. of
samples
Frame rate
[Hz]
Scanning
system
Subcarrier
frequency [MHz]
Aspect
ratio
Video level
[mV]
Sync level
[mV]
SETUP
Main countries
where used
NTSC-J (Japan)
NTSC
(RS-170A)
712 × 484 858 × 525 60/1.001 Interlaced 3.579545 4:3 714 286 No Japan
NTSC-M NTSC 712 × 484 858 × 525 60/1.001 Interlaced 3.579545 4:3 714 286 Yes USA
NTSC-443 NTSC 712 × 484 858 × 525 60/1.001 Interlaced 4.43361875 4:3 714 286 Yes
PAL-60 PAL 712 × 484 858 × 525 60/1.001 Interlaced 4.43361875 4:3 700 300 No
PAL-M PAL 712 × 484 858 × 525 60/1.001 Interlaced 3.57561189 4:3 714 286 Yes Brazil
PAL (B/D/G/H/I/K)
PAL
(BT.470-6)
702 × 574 864 × 625 50 Interlaced 4.43361875 4:3 700 300 No U.K, Germany
PAL-N PAL 718 × 574 864 × 625 50 Interlaced 4.43361875 4:3 714 286 Yes Uruguay
PAL-Nc PAL 702 × 574 864 × 625 50 Interlaced 3.58205625 4:3 700 300 No Argentina
SECAM SECAM 702 × 574 864 × 625 50 Interlaced for = 4.406250
fob = 4.250000
4:3 700 300 No France, Russia
483p
(NTSC-PROG)
SMPTE293M 720 × 483 848 × 525 60/1.001 Progressive - 4:3 700 300 - -
576p
(PAL-PROG)
BT.1358 720 × 574 864 × 625 50 Progressive - 4:3 700 300 - -
