ASTRO VG Series User Manual

Chapter 11 SPECIFICATIONS
463
11.1.8 DP unit (VM-1820 / 1820A)
Version supported VESA DisplayPort Standard Ver.1.1a
Connectors DisplayPort × 2
Single
Mode
16 to 270 MHz
However, according to each setting. (*1)
Dual Mode
DotCLK
Split Mode
32 to 340 MHz
However, according to each setting. (*1)
Audio output L-PCM Sampling frequency: 32/44.1/48/88.2/96 kHz
Output frequency: 100 to “half of the sampling
frequency” Hz
Number of bit: 16/20/24 bit
Number of colors
8 or 10 bits each for R, G and B (RGB and
YCbCr444 formats)
Link Rate 1.62 GHz/2.7 GHz DisplayPort
I/F
Number of
Lane
1/2/4 lanes
Input format S/PDIF format Audio input Optical
Sampling frequency Fs=32 to 96 kHz
DP1
DP2
Auxiliary channel support DPCD, EDID, DDC/CI, HDCP
*1 The maximum dot clock for DisplayPort is as follows according to the link rate, number of lanes, drawing mode,
bit length, and color format settings.
Item Maximum dot clock [MHz]
16 bit 18 bit 20bit 24 bit 30 bit Link
Rate
Lane
count
Drawing
mode
YC422
8 bit
RGB/
YC444
6 bit
YC422
10 bit
RGB/
YC444
8 bit
YC422
12 bit
RGB/
YC444
10 bit
Single 135 120 108 90 90 72 1
Dual/Split 270 240 216 180 180 144
Single 270 240 216 180 180 144 2
Dual/Split 340 340 340 340 330 288
Single 270 270 270 270 270 270
2.7
Gbps
4
Dual/Split
340 340 340 340 330 340
Single 81 72 64.8 54 54 43.2 1
Dual/Split 162 144 129.6 108 108 86.4
Single 162 144 129.6 108 108 86.4 2
Dual/Split 324 288 259.2 216 216 172.8
Single 324 288 259.2 216 216 172.8
1.62
Gbps
4
Dual/Split 340 340 340 340 330 340
*2 The DisplayPort output can be output at a horizontal timing of only 2-dot units in Single mode, or 4-dot units in
Dual or Split mode.
*3 When the YCbCr4:2:2 format has been selected, up to 12 bits can be set as the bit length. However, it is not
possible to display the gray scale which accords with the bit length (gray scale) which has been set (64-step gray
scale with an 8-bit output). Use this parameter to check the Main Stream Attribute parameters rather than using it
to assess the image quality.
*4 The maximum number of vertical scanning lines is 2046 for the DisplayPort output.
