466
11.1.10 4K2K (iTMDS, iTMDS Quad) unit (VM-1824, VM-1824-A)
DVI
MODE
8bit 25 to 165MHz (SingleLink)
50 to 330MHz (DualLink)
8-10bit 25 to 165MHz (SingleLink)
50 to 330MHz (DualLink)
iTMDS
MODE
12bit 25 to 150MHz (SingleLink)
50 to 300MHz (DualLink)
MULTI CH
MODE
10-16bit 25 to 165MHz (DualLink)
50 to 330MHz (QuadLink)
DotCLK
4Kx2K
MODE
8-12bit 296 to 660MHz (QuadLink)
592 to 1320MHz (OctalLink)
*1
Number of colors generated 16 bits each for R, G, B
Copy protection
HDCP Ver.1.0 *2
DVI1
DVI2
(DVI3)
(DVI4)
Additional function
E-EDID Ver1.3(DDC2B) *3
*1 Octal Link takes effect only when two output boards are used. It will not work when only one board is used.
*2 The VM-1824 (DVI Dual Link is equipped) does not support it.
*3 This has been supported starting with firmware version Ver.3.30.
Horizontal timing restrictions
Minimum horizontal blanking period 168 dots (384 dots in the 2-board mode)
Minimum horizontal display width 476 dots (996 dots in the 2-board mode)
●VM-1824(VM-1824-A)画面分割に対する設定単位
HVHV
Mode 0 2dot 2line 4dot 2line
Mode 1 4dot 1line 8dot 1line
Mode 2 2dot 2line 4dot 2line
Mode 3 4dot 1line 8dot 1line
HV
Mode 0 4dot(8dot)※ 1line
Mode 1 4dot(8dot)※ 1line
Mode 2 4dot(8dot)※ 1line
Mode 3 4dot(8dot)※ 1line
Mode 4 4dot(8dot)※ 1line
※IA-1540を使用して8分割出力を使用する場合は8dot単位の設定になりま
Quad Octal
Quad (x4Mode)
Setting increments for VM-1824 (VM-1824-A) screen splitting
* When the screen is split-output into 8 using IA-1540, the setting increment is 8-dot.
