ASTRO VG Series User Manual

Chapter 11 SPECIFICATIONS
471
11.3 Internal data
11.3.1 Program data
Sync
polarity
Program
No.
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
Dot clock
frequency
[MHz]
No. of display
dots
(H × V)
Int /
Prog
H V
SyncType
Color
difference
Timing data name Pattern data Pattern data name
1001 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB EIA640 × 480p@59.94
100%/100% color bars, horizontal
direction
Color Bar 100/100-H
1002 31.50 60.00 25.200 640 × 480 Prog N N ANALOG RGB EIA640 × 480p@60
100%/75% color bars, horizontal
direction
Color Bar 100/75-H
1003 31.47 59.94 27.000 720 × 480 Prog N N ANALOG YPbPr EIA720 × 480p@59.94
75%/75% color bars, horizontal
direction
Color Bar 75/75-H
1004 31.50 60.00 27.027 720 × 480 Prog N N ANALOG YPbPr EIA720 × 480p@60 SMPTE color bars Color Bar SMPTE
1005 31.47 59.94 27.000 720 × 480 Prog N N ANALOG YPbPr EIA720 × 480pW@59.94 RGBW color bars, vertical direction Color Bar RGBW-V
1006 31.50 60.00 27.027 720 × 480 Prog N N ANALOG YPbPr EIA720 × 480pW@60 xvYCC 4% color bars Color Bar xvYCC 4%
1007 44.96 59.94 74.176 1280 × 720 Prog P P HDTV720 YPbPr EIA1280 × 720p@59.94 xvYCC 8% color bars Color Bar xvYCC 8%
1008 45.00 60.00 74.250 1280 × 720 Prog P P HDTV720 YPbPr EIA1280 × 720p@60 xvYCC 12% color bars Color Bar xvYCC 12%
1009 33.72 59.94 74.176 1920 × 1080 Int P P HDTV1080 YPbPr EIA1920 × 1080i@59.94
100%/100% color bars, horizontal
direction 2
Color Bar 100/100-H2
1010 33.75 60.00 74.250 1920 × 1080 Int P P HDTV1080 YPbPr EIA1920 × 1080i@60
1011 15.73 59.94 27.000 1440 × 480 Int N N ANALOG YPbPr EIA1440 × 480i@59.94
1012 15.75 60.00 27.028 1440 × 480 Int N N ANALOG YPbPr EIA1440 × 480i@60
1013 15.73 59.94 27.000 1440 × 480 Int N N ANALOG YPbPr EIA1440 × 480iW@59.94
1014 15.75 60.00 27.028 1440 × 480 Int N N ANALOG YPbPr EIA1440 × 480iW@60
1015 15.73 60.05 27.000 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240p@59.94
1016 15.75 60.12 27.028 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240p@60
1017 15.73 59.83 27.000 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240p@59.94
1018 15.75 59.89 27.028 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240p@60
1019 15.73 60.05 27.000 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240pW@59.94
1020 15.75 60.12 27.028 1440 × 240 Prog N N ANALOG YPbPr EIA1440 × 240pW@60
Internal program data: No. 1001 to 1020
