ASTRO VG Series User Manual

348
6.11.2 Window pattern settings
The types of window patterns can be selected using the procedure below.
(1)
Select Program Edit using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select Pattern (PAT) using
or
INC
DEC
, and then press
SET
.
(3)
Select Pattern/RGB/INV select using
or
INC
DEC
, and then press
SET
.
(4)
Select Window using
or
INC
DEC
,
and then press
SET
.
(5)
Press
ESC
.
(6)
Select Window using
or
INC
DEC
,
and then press
SET
.
<Selecting the items>
Select the items using
or
INC
DEC
,
and then press
SET
.
(7)
<Setting the parameters>
Select the parameters using
or
INC
DEC
, and then press
SET
.
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For further details on the parameters, refer to <Table of
window setting items> below.
