Chapter 11 SPECIFICATIONS
469
11.1.13 Moving image module
Image memory 4GB (SO-DIMM 2GB × 2)
RGB (4:4:4)/10 bit Video format
YPbPr (4:2:2)/10 bit
Playback time Full HD (1920 × 1080)/60p RGB (4:4:4) approx. 8 sec.
YPbPr (4:2:2) approx. 12 sec.
11.1.14 External control
Dedicated remote controllers RB-1870, RB-1871
Serial control RS-232C
LAN 10/100BASE-T
11.1.15 General specifications
Supply voltage AC100 to 240 V
Power line frequency 50/60 Hz
Power consumption 80 VA MAX
Dimensions 430 (W) × 88 (H) × 370 (D) mm (excluding protrusions)
Weight Approx. 6.85 kg (when 3 output units have been installed)
Operating temperature range 5 to 40°C
Operating humidity range 30 to 80%RH (no condensation)
