ASTRO VG Series User Manual

Chapter 11 SPECIFICATIONS
461
11.1.3 TV encoder unit (VM-1812)
DotCLK 5 to 165 MHz
No. of colors generated 8 bits each for R, G, B
VGA
Connector Dsub × 1
DotCLK
HDTV (1920 × 1080i/1080p/720p), SDTV (720 ×
480p/480i)
No. of colors generated 8 bits each for R, G, B
D5
Connector D connector × 1 (D5 output supported)
DotCLK
HDTV (1920 × 1080i/1080p/720p), SDTV (720 ×
480p/480i)
No. of colors generated 8 bits each for R, G, B
YPbPr
Connector BNC × 3
DotCLK
NTSC-M/J/443, PAL (B/D/G/H/I)/M/N/Nc/60,
SECAM See below note
No. of colors generated 8 bits each for R, G, B
Connector COMPOSITE × 1, Y/C (S-VIDEO) × 1
COMPOSITE
Y/C
Additional functions
Teletext, Closed Caption, V-Chip, Macrovision
(options)
DotCLK
NTSC-M/J/443, PAL (B/D/G/H/I)/M/N/Nc/60,
SECAM See below note
No. of colors generated 8 bits each for R, G, B
Connector SCART × 2
SCART1
SCART2
Additional functions
Teletext, Closed Caption, V-Chip, Macrovision
(options)
Audio output RCA × 2
Output frequency 20 to 20 KHz
AUDIO
L/R
Output level 0 to 2000 mV
Note: VM-1812-B does not support PAL-N, PAL-60, SECAM. Option Pattern #77 (SMPTE color bar CVBS) is
not supported.
11.1.4 PC analog unit (VM-1811)
DotCLK 5 to 300 MHz
No. of colors generated 10 bits each for R, G, B
Video level 300 to 1200 mV (with VideoOnSync ON)
50 to 1200 mV (with VideoOnSync OFF)
Sync level HS/VS: TTL
VideoOnSync: 0 to 600 mV (2-level), 0 to ±600 mV
(tri-level)
VGA
RGB/HS/VS
DVI-I (analog unit)
Connector BNC × 3 (RGB), BNC × 2 (HS/VS), Dsub × 1
Sync level CS: 300 mV (2-level), 600 mV (tri-level) CS
Connector BNC × 1
DotCLK 25 to 165 MHz
No. of colors generated 8 bits each for R, G, B
Copy protection HDCP Ver1.0
Additional functions E-EDID Ver1.3 (DDC2B)
DVI-I (digital unit)
Connector DVI-I × 1 (HDCP supported)
