Chapter 4 INTERFACE SETTINGS
257
Set channel of Data stream 2. (this is valid for Dual Link / 3G Level B).
Note) this is available only when Mode is set by “1 (manual)”
0
1ch
1
2ch
2
3ch
The dynamic range of each value is used as the
setting.
(10)
Channel Assignment 2
(0-3)
3
4ch
This sets the dynamic range.
0
100%
1
200%
(11)
Dynamic Range(0-2)
2
400%
The dynamic range of each value is used as the
setting.
This sets the bit length.
0
8bit
1
10bit
(12)
Bit Depth(0-2)
2
12bit
The bit length of each value is used as the
setting.
4.14.3 Embedded audio
The embedded audio can be output as the SDI output.
For details of the setting procedure, refer to “4.16 Digital audio.”
