ASTRO VG Series User Manual

256
<SDI payload ID data setting parameters>
* These settings are for the payload ID data only. For details of the settings which directly affect the
transfer signals, refer to the respective items.
This sets the payload ID data to ON or OFF.
0
OFF
The payload ID data is not inserted.
(1)
OFF/ON (0/1)
1
ON
The payload ID data is inserted.
This is the setting for Byte1, Channel Assignment.
0
Refer Program
According to each data setting, the setting value
of Bye1 and Channel Assignment is followed.
Note) Byte1 and Channel Assignment1,
Channel Assignement2 are not displayed.
(2)
Mode (0/1)
1
Manual
Byte1 and Channel Assignment are set by
manually.
Set Byte1.
Note) this is available only when Mode is set by “1 (manual)”
(3)
Byte1
00 - FF
This sets the transport scanning mode.
0
Interlace
Interlace scanning
(4)
Transport (0/1)
1
Progressive
Progressive scanning
This sets the image scanning mode.
0
Interlace
Interlace scanning
(5)
Picture (0/1)
1
Progressive
Progressive scanning
This sets the frame rate.
0
23.98Hz
1
24Hz
2
25Hz
3
29.97Hz
4
30Hz
5
50Hz
6
59.94Hz
(6)
Picture Rate(0-7)
7
60Hz
The frame rate of each value is used as the
setting.
This sets the aspect ratio.
0
4:3
4:3 aspect ratio
(7)
Aspect Ratio(0/1)
1
16:9
16:9 aspect ratio
This sets the Y sampling value.
0
0
(8)
H Y-Sampling (0/1)
1
1
This set the sampling structure (video format)
0
4:2:2(YCbCr)
1
4:4:4(YCbCr)
2
4:4:4(RGB)
3
4:4:4:4(YCbCr+A)
4
4:4:4:4(RGB+A)
(9)
Sampling Struck(0-4)
5
4:4:4 (XYZ)
The video format of each value is used as the
setting.
Set channel of Data stream 1.
Note) this is available only when Mode is set by “1 (manual)”
0
1ch
1
2ch
2
3ch
(10)
Channel Assignment 1
(0-3)
3
4ch
