<SDI unit setting parameters>
This sets On or Off for each channel. (The same settings apply to channels 1
and 2 and to channels 3 and 4.)
These are the same settings as in “4.1.1 Setting the output interfaces to ON
or OFF.”
0
OFF
No output.
(1)
Output 1,2ch (0/1)
Output 3,4ch (0/1)
1
ON
Output.
This sets the SDI format.
* The format which is supported differs depending on the timing. For
details, refer to “11.1.11 SDI unit.”
0
SD
SD-SDI
1
HD
HD-SDI
2
3G-A
3G-SDI. Level.A
3
3G-B
3G-SDI. Level.B
4
Dual
Dual-Link
(2)
SDI Format (0-5)
5
3D
3D (Option)
* “3D” is an option. When the requisite license
has not been registered, sending using 3D is
not possible. For details, consult with an
ASTRODESIGN sales representative or your
distributor.
This sets the color space of the images which are output from SDI.
* The format which is supported differs depending on the timing. For
details, refer to “11.1.11 SDI unit.”
0
RGB
RGB
1
YCbCr4:4:4
YCbCr4:4:4
(3)
Video Format (0-2)
2
YCbCr4:2:2
YCbCr4:2:2
This sets the output image bit length. A setting which is independent of the
pattern drawing bit length can be selected or the same bit length as the
pattern drawing bit length can be selected automatically.
* The portion of the pattern drawing bit length which exceeds the bit length
set here is discarded. A deficient portion is filled with zeros.
Refer to “4.1.5 Setting the bit length (gray scale) for pattern drawing.”
* The format which is supported differs depending on the timing. For
details, refer to “11.1.11 SDI unit.”
0
Auto
Either 10 bits or 12 bits are selected
automatically in accordance with the pattern
drawing bit length.
1
10bit
10-bit output
(4)
Width(0-4)
2
12bit
12-bit output
This sets the embedded audio output.
* For details on the embedded audio settings, refer to “4.2.5 Embedded
audio, high bit rate audio (option).”
0
OFF
The embedded audio is not output.
(5)
Audio Output(0/1)
1
ON
The embedded audio is output.
(6)
Payload
This sets the payload ID data.
For further details, refer to <SDI payload ID data setting parameters> in the
next section.
