Chapter 9 VG-870/871 SYSTEM SETTINGS
429
9.1.18 Operation mode at power-on
The program to be executed immediately after turning on the power of the VG-870B/871B/873/874 can be set.
(1)
Select Configuration using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select General using
or
INC
DEC
,
and then press
SET
.
(3)
Select Power-On-Program using
or
INC
DEC
, and then press
SET
.
(4)
Select the setting using
or
INC
DEC
,
and then press
SET
.
Alternatively:
Select the setting using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
<Reference>
None (not execute):
The program is not executed when the generator’s power is
turned on.
Configuration:
The program which was set in step (5) is executed.
Last Memory:
The Last Memory operation (the program which was
executed immediately before the generator’s power was
turned off) is executed.
However, some restrictions apply. Refer to * below.
(5)
<When Configuration has been selected>
Select the setting using or
INC
DEC
,
and then press
SET
.
Alternatively:
Select the setting using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
Select the type of data at Type.
<Type>
SAMPLE TIM/PAT:
Internal sample data (timing data or pattern data)
USER Program:
Program data created and registered by the user
Group:
Group data created and registered by the user
* Last Memory restrictions
1. The user program will be executed in cases where the data types differ such as when internal sample data is
selected as the timing data and a user program is selected as the pattern data. (Example: When TIM=1001
and PAT=1, TIM=PAT=1 is executed.)
2. The timing data number will be executed in cases where user programs are selected as both the timing data
and pattern data but their numbers differs. (Example: When TIM=5 and PAT=1, TIM=PAT=5 is executed.)
3. When Last Memory is executed using a group, the data at the head of the group will be executed.
