1.3 Data configuration
The data output by the VG-870B/871B is managed by the program data.
The program data consists of the pattern data which is used to set the data relating to the output images
and the timing data which is used to set the data relating to all other output timing data and output
conditions.
The table below gives a breakdown of the data.
Block Description
Program Name Program name
Timing Timing
Output Output condition
Timing data
AUDIO Audio output
Pattern Pattern Pattern data
Action Pattern action
A number of types of program data, optional patterns and user character patterns are contained as
sample data inside the VG-870B/871B.
Number of data
Timing data 1000 (Timing # 1001 to 2000)
Pattern data 1000 (Pattern # 1001 to 2000)
Optional patterns 200 (1 to 200)
User character patterns 16 (F0H to FFH)
The various data can be registered in the internal memory (approx. 100 MB)
of the
VG-870B/871B/873/874 or on CF cards.
Number of data
Program data 1000 (Program # 1 to 1000)
User option patterns 200 (1 to 200)
Images (image data) 200 (1 to 200)
* Number of data depends on the image data size,
memory capacity and card capacity.
User character patterns 16 (E0H to EFH)
Number of characters in program names 20 characters
Number of groups 99 (1 to 99)
Number of group data 98 (1 to 98)
Number of characters in group names 20 characters
* For further details on groups, refer to
“2.4 Groups.”
* For further details, refer to “9.1.11 Image - priority settings.”
When a CF card has been inserted, the data registered on that
card becomes valid, and the data registered in the internal
memory becomes invalid.
In the case of image data, both the data on a CF card and the
data in the internal memory can be made valid. *
CAUTION
