180
<SCART setting parameters>
This sets On or Off for each channel.
The same settings as the ones described in “4.1.1 Setting the output
interfaces to ON or OFF” can also be established.
0
Off
No output.
(1)
Output 1ch (0/1)
Output 2ch (0/1)
1
On
Output.
This sets the format of the video signals which are output from the SCART
connector.
0
COMPOSITE
Composite signals are output.
1
Y/C
Y/C signals are output.
(2)
Output Select (0-2)
2
RGB
RGB signals are output.
This sets the video status signal which is output from the SCART connector.
0
Auto
The setting accords with the program setting.
1
4:3
4:3 (identified voltage: 12 V (9.5 to 12.0 V))
2
16:9
16:9 (identified voltage: 5 V (4.5 to 7.0 V))
(3)
Video Status (0-3)
3
No Signal
No output. (identified voltage: 0 V (0.0 to 2.0 V))
This sets the RGB status signal which is output from the SCART connector.
0
Auto
The signal is set automatically by Output
Select.
1
VBS
Composite or Y/C signals
(identified voltage: 0 V)
2
RGB
RGB (identified voltage: 5 V)
(4)
RGB Status (0-3)
3
Fast Blanking
The fast blanking signal is output.
This sets the output range of the fast blanking signal.
H
The horizontal output range is set as a percentage of H-Disp.
Setting range: 0% to 100%
(5)
Fast Blanking Area
V
The vertical output range is set as a percentage of V-Disp.
Setting range: 0% to 100%
This sets on or off for each channel.
0
OFF
No output.
(6)
Audio Out1ch (0/1)
1
ON
Output.
(7)
Audio Out2ch (0/1)
This setting is the same as for the Audio Out1ch setting.
4.11.3 Functions available with TV standard signals
Macrovision, closed caption, V-Chip, Teletext, WSS and CGMS-A/ID-1 can be multiplexed with the
composite signals and Y signal.
For details on the setting procedure, refer to “5.
FUNCTIONS AVAILABLE WITH TV STANDARD
SIGNALS.”
4.11.4 Filter settings
For further details on the setting procedure, refer to “4.8.2 Composite signal filter settings.”
