11.1.5 DVI unit (VM-1814)
25 to 165 MHz (to 8 bits)
Single Link
25 to 165 MHz (to 16 bits)
DotCLK
Dual Link 50 to 330 MHz (to 8 bits)
No. of colors generated 16 bits each for R, G, B
Copy protection None
Additional functions E-EDID Ver1.3 (DDC2B)
DVI1
Connector DVI-D × 1 (Dual Link supported)
DotCLK 25 to 165 MHz (to 8 bits)
No. of colors generated 8 bits each for R, G, B
Copy protection HDCP Ver1.0
Additional functions E-EDID Ver1.3 (DDC2B)
DVI2
Connector DVI-D × 1 (HDCP supported)
11.1.6 LVDS unit (VM-1815)
Single Link 20 to 135 MHz (to 16 bits)
Dual Link 40 to 270 MHz (to 14 bits)
40 to 240 MHz (to 16 bits)
DotCLK
Quad Link 80 to 340 MHz (to 10 bits)
No. of colors generated 16 bits each for R, G, B
LVDS1
LVDS2
LVDS3
LVDS4
Connector LVDS × 4
11.1.7 PARALLEL unit (VM-1816)
Single Link 0.1 to 100 MHz (to 16 bits)
DotCLK
Dual Link 0.2 to 200 MHz (to 8 bits)
No. of colors generated 16 bits each for R, G, B
Output voltage level
Output signal voltage level (SIGNAL) and output
power supply voltage level (POWER) settings
Positions of the switches Voltage level [V]
1 1.8
2 2.5
3 3.3
4 5
PARALLEL1
PARALLEL2
Connector PARALLEL × 2
