13.3 HDCP-related error
Code (HEX) Error message Description
403 HDCP) Transmitter KSV Error KSV of the transmitter does not contain twenty ‘0’s and ‘1’s.
404 HDCP) Receiver KSV Error KSV of the receiver does not contain twenty ‘0’s and ‘1’s.
405 HDCP) Link Check Error During initial validation, the values did not match (R0 ≠ R0’).
406 HDCP) Encryption Error Encryption was not completed.
407 HDCP) Hot Plug Error The device to be connected is not connected.
408 HDCP) Ri Ready Error The ready bit of the receiver was not set high.
412 HDCP) I2C Line Error The I2C line is not working properly.
414 HDCP) Receiver Not HDMIMode
The connected device (receiver) was not set to the HDMI mode when
the HDCP version was identified as 1.1 as a result of HDCP
version:1.1 or HDCP version: EDID check.
415 HDCP) Ri NG The values of Ri and Ri’ do not match.
416 HDCP) FIFO Ready Time-out FIFO Ready fails to occur within restricted time limit.
417 HDCP) DEPTH Error The depth number has exceeded ‘7’.
418 HDCP) DEVICE_COUNT Error The count number has exceeded ‘127’.
419 HDCP) List Error (V’!=V) The values of V and V’ do not match.
13.4 User-generated optional pattern-related error
Code (HEX) Error message Description
501 OPT Program Not Found The user-generated optional pattern is not found.
502 Variables Stack Error Variable stack error.
503 Register Stack Error Register stack error.
504 Call Stack Error Function stack error.
505 Illegal Instruction Code Illegal instruction code.
506 Divide by Zero An attempt was made to divide a number by zero.
539 OPT-USER License Error The user-generated optional pattern license has not been supplied.
