ASTRO VG Series User Manual

360
6.13.3 EDID
The EDID of the connected display can be displayed on the screen.
a) EDID display method
(1)
NAME/LIST
DETAIL
NAME/LIST
DETAIL
(2)
<Displaying the EDID>
Select EDID using
or
INC
DEC
, and
then press
SET
.
Alternatively, select
4/A
for the GUI display
format or
5/B
for the HEX display format.
The EDID is displayed as shown in the figure below.
(3)
<Selecting the pages>
Select (previous page) or
(next page)using or
INC
DEC
, and then press
SET
.
Alternatively, select the page using
2
(previous page) or
3
(next page).
When the display extends over several pages, it is divided
up on the fluorescent display tube, and shown. (Switch
from one page to another to display all the information.)
