ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
151
Setting (2) [Dual (10 bits)], [Normal]
The images are output with channels 1 and 2 forming one set and channels 3 and 4 forming another set.
The output level is 8 to 10 bits.
The example is that the resolution is 1280 × 1024, the dot clock frequency is 108 MHz, with the 10 bits output..
D 0
[9：0]
D 2 D 4 D 6
・・・
・・・
[9：0] [9：0] [9：0]
D 1272
[9：0]
D 1274 D 1276 D 1278
[9：0] [9：0] [9：0]
CLK
54MHz
D 1
[9：0]
D 3 D 5 D 7
・・・
[9：0] [9：0] [9：0]
D 1273
[9：0]
D 1275 D 1277 D 1279
[9：0] [9：0] [9：0]
1CH
2CH
3CH
4CH
D 0
[9：0]
D 2 D 4 D 6
・・・
[9：0] [9：0] [9：0]
D 1272
[9：0]
D 1274 D 1276 D 1278
[9：0] [9：0] [9：0]
D 1
[9：0]
D 3 D 5 D 7
・・・
[9：0] [9：0] [9：0]
D 1273
[9：0]
D 1275 D 1277 D 1279
[9：0] [9：0] [9：0]
1CH
2CH
3CH
4CH
