Chapter 4 INTERFACE SETTINGS
165
Bit arrays for 8 to 16 bits for using two output connector
Config setting: MultiBitMode/10+6 Bit
8- to 16-bit mode
SAMPLE1
(DISM)
SAMPLE1
(OpenLDI)
USER
Operation
signal
Data No.
CH1,CH2 CH3,CH4 CH1,CH2 CH3,CH4 CH1,CH2 CH3,CH4
TA0 R10 R0 R6 R0 R (X) R (X)
TA1 R11 R1 R7 R1 R (X) R (X)
TA2 R12 R2 R8 R2 R (X) R (X)
TA3 R13 R3 R9 R3 R (X) R (X)
TA4 R14 R4 R10 R4 R (X) R (X)
TA5 R15 R5 R11 R5 R (X) R (X)
TA
TA6 G10 G0 G6 G0 G (X) G (X)
TB0 G11 G1 G7 G1 G (X) G (X)
TB1 G12 G2 G8 G2 G (X) G (X)
TB2 G13 G3 G9 G3 G (X) G (X)
TB3 G14 G4 G10 G4 G (X) G (X)
TB4 G15 G5 G11 G5 G (X) G (X)
TB5 B10 B0 B6 B0 B (X) B (X)
TB
TB6 B11 B1 B7 B1 B (X) B (X)
TC0 B12 B2 B8 B2 B (X) B (X)
TC1 B13 B3 B9 B3 B (X) B (X)
TC2 B14 B4 B10 B4 B (X) B (X)
TC3 B15 B5 B11 B5 B (X) B (X)
TC4 HS HS HS HS HS HS
TC5 VS VS VS VS VS VS
TC
TC6 DE DE DE DE DE DE
TD0 R8 L R12 L R (X) L
TD1 R9 L R13 L R (X) L
TD2 G8 L G12 L G (X) L
TD3 G9 L G13 L G (X) L
TD4 B8 L B12 L B (X) L
TD5 B9 L B13 L B (X) L
TD
TD6 L L L L L L
TE0 R6 L R14 L R (X) L
TE1 R7 L R15 L R (X) L
TE2 G6 L G14 L G (X) L
TE3 G7 L G15 L G (X) L
TE4 B6 L B14 L B (X) L
TE5 B7 L B15 L B (X) L
TE
TE6 L L L L L L
* If bit width smaller than 16-bit, the lower bits are discarded and the placed upward.
