ASTRO VG Series User Manual

Chapter 4 INTERFACE SETTINGS
193
d) Concerning the Main Stream Attribute settings
The Main Stream Attributes used for DisplayPort transfer are reflected by the following settings.
Item Setting location
Mvid
This is automatically calculated from the Nvid setting value
and the dot clock.
(The VG-870B/871B/873/874 is fixed to asynchronous
mode, so the Mvid value varies.)
M and N for stream
clock recovery
Nvid
The setting is followed by the DisplayPort setting “Nvid”.
Refer to “<DP unit setting parameters>” in this section.
Total
Active start
Active video width
Sync width
This is calculated from the value set by the Timing setting.
For further details, refer to “Timing setting”.
Horizontal/Vertical
Timing
polarity
The setting is followed by the sync signal polarity set by the Output
setting.
For further details, refer to “4.1.2 Setting the sync signals to ON or
OFF and setting the sync signal polarities”
Synchronous Clock The VG-870B/871B/873/874 are fixed to asynchronous mode.
Component format The setting is followed by the DisplayPort setting “Video Format”.
Refer to “<DP unit setting parameters>” in this section.
Full: VESA range
Limited: CEA range
Dynamic range The setting is followed by the Output setting “Level Mode”.
For further details, refer to “4.1.3 Setting the level mode”.
YCbCr Colorimetry The setting is followed by the DisplayPort setting “Colorimetry”.
Refer to “<DP unit setting parameters>” in this section.
Miscellaneous0
Bit depth per color
component
The setting is followed by the DisplayPort setting “Width”.
Refer to “<DP unit setting parameters>” in this section.
Other
Settings except above are not supported by the
VG-870B/871B/873/874.
