<V-by-One HS setting parameters>
This sets On or Off for each channel.
0
Off
No output.
(1)
Output 1ch (0/1)
Output 2ch (0/1)
1
On
Output.
This sets the number of data lanes to be output from V-by-One HS.
The number of data lanes is changed
automatically in line with the dot clock frequency.
* Only lanes 1 to 4 are supported.
20M - 75 MHz 1 Lane
75M - 150 MHz 2 Lane
0
Auto
150M - 300 MHz 4 Lane
1
1 Lane
The image is output using one lane as the
number of data lanes.
The same image is output from output channels
1 and 2.
2
2 Lane
The image is output using two lanes as the
number of data lanes.
The same image is output from output channels
1 and 2.
3
4 Lane
The image is output using four lanes as the
number of data lanes. The same image is
output from output channels 1 and 2.
4
8 Lane
The image is output using eight lanes as the
number of data lanes.
(2)
Number Of Lane (0/5)
5
16 Lane
The image is output using 16 lanes as the
number of data lanes.
This selects the screen splitting type in the ×4 mode or 4K×2K mode which
uses the frame memory on the board.
8 Lane
0
MODE0
Split-into-4 output in the form of a square divided
into 4 equal parts
1
MODE1
Vertically split-into-4 output
2
MODE2
Horizontally split-into-2 output
3
MODE3
Vertically split-into-2 output
4
MODE4
No split
5
MODE0(x4 mode)
Non Dividing Mode
6
MODE1(x4 mode)
Normal Mode
7
MODE2(x4 mode)
Cross Mode
8
MODE3(x4 mode)
Dividing Normal Mode
9
MODE4(x4 mode)
Dividing Cross Mode
0
MODE0
Cross split to 4 + vertically split to 2
1
MODE1
Vertically split to 4 + vertically split to 2
2
MODE2
Horizontally split to 2 + vertically split to 2
3
MODE3
Vertically split to 2 + vertically split to 2
4
MODE4
Vertically split to 2 + No split (1)
(Non dividing Mode)
5
MODE5
Vertically split to 2 + No split (2)
(Normal Mode)
6
MODE6
Vertically split to 2 + No split (3) (Cross Mode)
7
MODE7
Vertically split to 2 + split (1)
(Dividing Normal Mode)
8
MODE8
Vertically split to 2 + split (2)
(Dividing Cross Mode)
(3)
Split(0/9)
9
MODE9
No split
This sets the pre-emphasis.
0
0%
The pre-emphasis is set to 0%.
(4)
Pre-Emphasis(0/1)
1
100%
The pre-emphasis is set to 100%.
