ASTRO VG Series User Manual

346
<Setting the items>
Select the items using
or
INC
DEC
,
and then press
SET
.
(8)
<Setting the parameters>
Select the parameters using
or
INC
DEC
, and then press
SET
.
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For further details, refer to <Table of burst setting items>
below.
<Table of burst setting items>
The origin point of the pattern drawing is set here.
0
L->R
The line width increases from left to right.
1
L<-R
The line width increases from right to left.
2
L<-C->R
The line width increases from the center to the
left edge and from the center to the right edge.
3
L->C<-R
The line width increases from the left edge to the
center and from the right edge to the center.
4
T->B
The line width increases from top to bottom.
5
T<-B
The line width increases from bottom to top.
6
T<-C->B
The line width increases from the center to the
top edge and from the center to the bottom
edge.
(1)
Format (0-2)
7
T->C<-B
The line width increases from the top edge to the
center and from the bottom edge to the center.
(2)
Number of Line
The number of lines set here is repeatedly drawn with the same thickness.
After the set number of lines has been drawn, the thickness is increased by
an amount equivalent to the Step setting, and this is repeated.
Setting range: 1 to 99
(3)
Step
The step is set here.
Setting range: 0 to 99 [dot]
