<Table of subtitle setting items>
(1)
No.
The number of the image pattern to be displayed is set here.
Setting range: 1 to 200
The position where the pattern is to be displayed is set here.
0
User Position
Setting position of User Position in (3)
1
Top-Left
Top left
2
Middle-Left
Center left
3
Bottom-Left
Bottom left
4
Top-Center
Center top
5
Center
Center
6
Bottom-Center
Center bottom
7
Top-Right
Top right
8
Middle-Right
Center right
(2)
Position (0-9)
9
Bottom-Right
Bottom right
(3)
User Position
The desired display position (coordinate for the top left of the pattern) is set
here.
The setting takes effect when User Position has been selected as the
Position setting.
Setting range: 0 to 9999
The display colors are set here.
0
File Data
The colors of the image pattern data are
displayed in their original form.
(4)
Color Select (0/1)
1
User Color
The settings for User Color1-3 in (5) are used.
Color
Depth
Setting range
8BIT
0 - 255
9BIT
0 - 511
10BIT
0 - 1023
11BIT
0 - 2047
12BIT
0 - 4095
13BIT
0 - 8191
14BIT
0 - 16383
15BIT
0 - 32767
(5)
User Color1 to 3 R,G,B
The desired display colors are set here.
The setting takes effect when User Color has been
selected as the Color Select setting.
The setting range differs depending on the color
depth.
16BIT
0 - 65535
