ASTRO VG Series User Manual

512
Sync
polarity
Program
No.
Horizontal
frequency
[KHz]
Vertical
frequency
[Hz]
Dot clock
frequency
[MHz]
No. of display
dots
(H × V)
Int /
Prog
H V
SyncType
Color
difference
Timing data name Pattern data Pattern data name
1951 33.75 60.00 74.250 1920 × 1080 Int N N HDTV1080 YPbPr 1080i
1952 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB VGA480-60
1953 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB VGA480-60
1954 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB VGA480-60
1955 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB VGA480-60
1956 31.22 49.98 46.200 1170 × 1168 Int N N ANALOG RGB MEDICAL-1I
1957 31.22 50.03 46.200 1170 × 584 Prog N N ANALOG RGB MEDICAL-1N
1958 30.69 60.00 36.830 947 × 946 Int N N ANALOG RGB MEDICAL-2I
1959 30.69 60.06 36.830 947 × 473 Prog N N ANALOG RGB MEDICAL-2N
1960 37.93 85.04 35.500 720 × 400 Prog N P ANALOG RGB VESA400-88
1961 112.5 90.00 243.000 1600 × 1200 Prog N N ANALOG RGB 1200-90
1962 31.47 59.94 25.175 640 × 480 Prog N N ANALOG RGB VGA480-60
1963 63.98 60.02 108.000 1280 × 1024 Prog P P ANALOG RGB VESA1024-60
1964 15.63 50.00 13.500 702 × 574 Int N N SECAM YPbPr SECAM
1965 31.47 59.94 34.240 864 × 480 Prog N N ANALOG RGB W-VGA
1966 37.88 60.32 53.940 1072 × 600 Prog N N ANALOG RGB W-SVGA
1967 48.36 60.00 87.440 1376 × 768 Prog N N ANALOG RGB W-XGA
1968 15.73 59.94 13.500 712 × 484 Int N N NTSC YPbPr NTSC
1969 15.63 50.00 13.500 702 × 574 Int N N PAL YPbPr PAL
1970 67.5 60.00 148.500 1920 × 1080 Prog N N HDTV1080 YPbPr 1080P
Internal program data: No. 1951 to 1970
