60
<HDMI unit setting parameters>
Set on or off for each channel here.
The same settings as the ones described in “4.1.1 Setting the output
interfaces to ON or OFF” can also be established.
0
Off
No signal output
(1)
Output 1ch (0/1)
Output 2ch (0/1)
1
On
Signal output
An HDMI connection can be made to DVI by cable conversion.
Set the operations at this time here.
0
HDMI
The full functions of HDMI can be used.
1
DVI
This setting differs from HDMI in the following
ways.
Info Frame and Packet are not sent.
Audio is not supported.
Up to 8 bits are supported. Deep Color is not
supported. Even if “Color Depth” is set as 10-bit or
higher, the actual output is 8-bit. (lower 2-bit is
deleted.)
(2)
HDMI or DVI (0-2)
2
Auto
EDID of the connected monitor is checked, and
the DVI and HDMI modes are set.
The color space of the images output from HDMI is set here.
0
RGB
The images are output using RGB signals.
1
YCbCr4:4:4
The images are output using YCbCr4:4:4 signals.
2
YCbCr4:2:2
The images are output using YCbCr4:2:2 signals.
(3)
Video Format (0-2)
3
YCbCr4:2:0
The images are output using YCbCr4:2:0 signals.
The bit length of the images output from HDMI is set here. A setting
independent of the bit length for pattern drawing can be selected or the
same bit length can be selected automatically.
* The portion by which the bit length for pattern drawing exceeds the
bit length which has been set here is discarded. A deficient portion is
filled with zeros.
Refer to “4.1.5 Setting the bit length (gray scale) for pattern drawing.”
0
Auto
8, 10 or 12 bits are selected here automatically
depending on the bit length for pattern drawing.
1
8 bit
8-bit output
2
10 bit
10-bit output
3
12 bit
12-bit output
(4)
Width (0-4)
4
16 bit
16-bit output (only for VM-1823)
The embedded audio output is set here.
* For the embedded audio settings, refer to “4.2.5 Embedded audio,
high bit rate audio (option).”
0
Off
No embedded audio output
(5)
Audio Output (0/1)
1
On
Embedded audio output
The audio N parameter is set here.
* This setting is optional. It can be set only when the CTS license has
been registered. When it has not been registered, it is fixed at Auto.
* VM-1823 does not support this function.
0
Auto
The appropriate value is set.
(6)
Audio N (0/1)
1
Manual
128×fs/A
The N value, calculated using the following
formula, is set:
N = 128 × sampling frequency / A
Where the setting range of A: 300 to 1500
(7)
InfoFrame
When sending InfoFrame automatically in line with the color space and
other settings, refer to “4.2.3 InfoFrame/Packet”
When sending InfoFrame with the data of the user’s choice, refer to
“4.2.3 InfoFrame/Packet”
To Next Page
