Bosch EPS 118 - Technical Data and Specifications

1 689 989 300 2020-03-24| Robert Bosch GmbH
Technical Data | EPS 118 | 89
10.5 Electromagnetic compatibility
(EMC)
The EPS 118 satisfies the requirements of the EMC
directive 2014/30/EU.
i The EPS 118 is a class/category B product as defi-
ned by EN 61 326. The EPS 118 may cause high-fre-
quency household interference (radio interference)
so that interference suppression may be necessary.
In such cases the user may be required to take the
appropriate action.
en
10. Technical Data
10.1 EPS 118
Function Specification
Single phase AC voltage (U
AC
) 100 V – 240 V ±10 %
Rated current 2.5A
Fuse 5 A
Number of phases 1P - PE
Input frequency 50Hz / 60Hz
Rated power 450W
Possible power supply for USB devices
connected to the USB port
≤ 500mA
Storage Temperature -25°C – 60°C
Operating Temperature
1)
5°C – 40°C
Ambient temperature
for measurement accuracy
10°C – 35°C
Max. perm. relative humidity ≤90% (25°C,
24hours duration)
Degree of protection IP 32
Oil pressure 180MPa
Control voltage (U
DC
) 12 V
Atmospheric pressure corresponding
to an altitude of
700 hPa – 1060 hPa
≤2200m
Pressure input 0.65− 0.85MPa
Compressed air requirement
2)
≥ 320 l
n
/min
1)
Longer conditioning times must be expected at ambient tem-
peratures above 25°C.
2)
Compressed air quality in accordance with ISO 8573–1:2010
[3:4:4]
Function Specification
Tightening torque for the connection
adapter, sealing plug and high-pressure
hose assembly
25Nm − 30Nm
Test oil tank capacity 6 l
10.2 Compressor
i The compressor does not come with the
EPS 118and must be provided by the operator to
operate the EPS 118.
Function Specification
Compressed air tank volume ≥ 100 l
Switch-on pressure ≥ 0.7 MPa
Delivery pressure 0.65− 0.85MPa
Pump line
*)
≥ 320 l
n
/min
Length of the hose which connects
the EPS 118 to the compressor
≤ 10m
Inner diameter of the hose which
connects the EPS 118 to the com-
pressor
≥ 10mm
Inner diameter of the hose connec-
tions
≥ 7.5mm
*)
Amount of air provided by the compressor. Do not confuse this
with the compressor suction capacity.
10.3 Noise emissions
Function Specification
Emission sound pressure level
at workplace as per DIN EN ISO 11201
< 62 dB(A)
Sound power level as per DIN EN ISO 3744 < 69 dB(A)
10.4 Dimensions and weights
Function Specification
EPS 118 (H x W x D) 580 x 600 x 600 mm
Weight of EPS 118 incl. packaging 78kg
Weight of the EPS 118 without test oil
and packaging
64kg
