7.6.11 Network connection Left Network and Right Network
Fig. 74:
C
E
D
A
B
557 186-68
Network connection Left Network and Right Network
 Connect the network
cables according to the
circuit diagram.
A:
RJ45 Network cable
Right Network
B:
RJ45 Network cable
Left Network
C:
Network
Right Network
D:
Curve module,
network supply
E:
Network
Left Network
