Bosch Rexroth ActiveMover - Calibration Set 3 842 559 456

About this product 47/188
3 842 564 874/2021-04, MIT: ActiveMover, Bosch Rexroth AG
5.2.17 Calibration set 3 842 559 456
Fig. 26:
B
A
C
E
D
F
557 186-26
Calibration set
Please note:
The calibration set is
required for adjusting/
calibrating the measuring
system on the WT.
A:
Position indicator
B:
Reference system
C:
Alignment block
D:
Knurled screw
E:
Fixing element
F:
Knurled screw
