7.6.15 Ethernet POWERLINK
Fig. 78:
B
A
557 186-72
Ethernet POWERLINK connection
Please note:
• This wiring is inside the
ActiveMover control
panel and provides the
connection from the
controller to the bus
controller.
• The connection cable is
included in the scope of
delivery.
 Connect the ActiveMover
controller to the bus
controller according to
the circuit diagram.
A: Ethernet POWERLINK
port
B: Ethernet POWERLINK
port
