Bosch Rexroth ActiveMover - Diagnostic Leds; Activemover Controller; Printed Circuit Board (Coil Driver)

Troubleshooting 179/188
3 842 564 874/2021-04, MIT: ActiveMover, Bosch Rexroth AG
11.4 Diagnostic LEDs
11.4.1 ActiveMover controller
(in the control cabinet)
LED Color Condition Normal state Possible error
Power Green ON

Flashing Controller hardware error
• Contact the customer service
Red ON Controller switched off
• Switch on controller
Flashing Controller hardware error
• Contact the customer service
Red/green Flashing
HDD Yellow Partly fl ashing

Link Yellow ON If an SDL display is
connected
Flashing SDL display voltage supply interrupted
• Check connection lines
OFF If no SDL display is
connected
Run Green ON

Flashing

The controller start sequence has not
yet been completed
• Wait a few minutes
Red ON Controller software error
• Contact the customer service
Flashing
11.4.2 Printed circuit board (coil driver)
(in the electronics box of the section/curve modules)
LED color Condition Normal state Possible error
Green ON

OFF Voltage supply deactivated
• Switch on the voltage supply
Red ON The A/D CPLD (Complex Programmable
Logic Devices) is not programmed
• Contact the customer service
OFF

