Pos. LED Color Condition Normal state Possible error
D 8 Red As desired — Software diagnostic LED, only for
development purposes
D 9 Yellow As desired —
G 10 TEMP
1
Yellow ON

Last printed circuit board
(gateway) in the network
OFF

Not the last printed circuit board
(gateway) in the network
F 11 TEMP
1
Yellow ON

Printed circuit board (gateway) is
confi gured for the left network
OFF

Printed circuit board (gateway) is
confi gured for the right network
B 13 Red ON Voltage supply switched off due
to excessive load current
• Short circuit on the encoder
board or the encoder
connection cable
OFF

A 14 Red ON Voltage supply for IR probe
switched off due to excessive load
current
• Short circuit of the IR reading
head or IR reading head
connection line
OFF

1 printed circuit boards (gateway) that were produced before mid-2016 and not received a CPLD
fi rmware update have the following signaling:
Pos. LED Color Condition Normal state Possible error
G
and
F
10 TEMP
and
11 TEMP
Yellow ON Defective thermistor detected
Fast fl ashing Max. operating temperature
exceeded
OFF

Motor
temperature in
the permitted
range
12 Decommissioning
This product is a component which does not need to be decommissioned.
Accordingly, this section has been left blank.
