Dimensions, mass, insulation, sound pressure level
Data for mass, dimensions, sound pressure level, insulation
Description Symbol Unit
KMV03.1R-
A05K0-P-D7-
ET-NNNN
KMV03.1R-
B0007-P-D7-
ET-NNNN
KMV03.1R-
I01K5-P-D7-
ET-NNNN
KMV03.1R-
W06K0-P-D7-
ET-NNNN
Mass m kg 20.00 15.70 20.00
Device height
1)
H mm 360 280 360
Device depth
2)
T mm 280 230 280
Device width
3)
B mm 330 325 330
Insulation resistance at 500 V DC
R
is
Mohm > 50
Capacitance against housing
5)
C
Y
nF 150 + 200
Average sound pressure level
(accuracy class 2) at P
DC_cont
4)
L
P
dB (A) < 50 < 60
Latest amendment: 2019-08-08*
1) 2) 3) Housing dimension; see also related dimensional drawing
4) According to DIN EN ISO 11205; comparative value at 1 m dis‐
tance
5) 150 nF: L+ against ground; 200 nF: L- against ground
Tab. 5-10: KMV - Data for mass, dimensions, sound pressure level, insulation
94/407
Technical data of the components
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
