Components Features
RKH, hybrid cable
RKH0xxx
DC bus connection
Control voltage and signal exchange cable
Communication cable
RKH0800
Mains voltage
Mains contactor
RKH0801
Mains choke
Mains voltage synchronization
The hybrid cable is supplied in ready-made form with connectors.
The bulk cable (hybrid cable without connector) is named REH0800
(hybrid cable incl. communication) or REH0803 (hybrid cable without
communication; devices with external communication (ES option) use
separate cables for communication).
Tab. 1-1: IndraDrive Mi with KMS03 – Features
Cooling types
Thermal interface
(cold plate, insulated mounting)
Forced cooling Natural convection
Tab. 1-2: Cooling types (example: KMV03)
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
5/407
System presentation
