5.6.3 KLC03.1N-A04M7 dimensional drawing (natural convection)
A Minimum mounting clearance
B Boring dimensions
Fig. 5-28: KLC03.1N-A04M7 (natural convection), dimensions
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
103/407
Technical data of the components
R911335703_Edition 04 Bosch Rexroth AG
