1.3.4 KMS03 near motor servo drive
KMS03 type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: K M S 0 3 . 1 B - A 0 3 6 - P - D 7 - E T - E N D - L 3 - T O - F W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬
① Product:
KMS = KMS
② Series:
03 = 3
③ Design:
1 = 1
④ Performance:
B = Basic
⑤ Cooling type:
A = Natural convection (exterior heat sink)
B = Thermal interface
⑥ Maximum current:
036 = 36 A
⑦ Degree of protection:
P = IP65
⑧ Nominal DC bus voltage:
D7 = DC 750 V
⑨ Master communication:
ET = Multi-Ethernet
⑩ Encoder interface:
END = Encoder Hiperface and digital encoder
⑪ Safety option:
L3 = Safe Torque Off (STO)
SD = Safe Motion
NN = Without
⑫ Other design:
ES = External master communication Multi-Ethernet (2 × M12)
NN = Without
TO = Multi-Ethernet output coupling (2 × M12)
⑬ Firmware:
FW = Firmware is required to operate the device
Tab. 1-10: Type code KMS03
