6.6.10 XG3, mains choke temperature contact
View Connection Function
1 Connection to mains filter (mains choke temperature
contact XG3.1/2)
2
Tab. 6-62: Pin assignment
Mechanical data
Spring terminal (connector) Unit max.
Connection cable
Stranded wire
mm
2
1.5
AWG 16
Stripped length mm 10
Tab. 6-63: Mechanical data
Cables
Description Value
Order type RKH0801
Maximum allowed length 1 m
Tab. 6-64: Cables
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
203/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
