6 Connection points
6.1 System connection points
6.1.1 Connection point of equipment grounding conductor
Cabinet-bound drive systems
Dangerous contact voltage at device housing!
Lethal electric shock!
The devices of the IndraDrive Mi product range are devices with increased
leakage current (greater than AC 3.5 mA or DC 10 mA).
Therefore, always install a stationary connection of the equipment grounding
conductor.
In a IndraDrive Mi drive system, connect the equipment grounding conductor
connections of all devices and additional components to the equipment
grounding system.
Risk of damage to the devices by spark
discharge of static charges
In some applications (e.g., printing or packaging), high static charges can
develop. Make sure that these charges can be directly discharged against
ground at their point of origin. Therefore, connect the second connection
point of equipment grounding conductor of the devices to the equipment
grounding system of the installation.
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
141/407
Connection points
R911335703_Edition 04 Bosch Rexroth AG
