10.11 HAS10, mechanical mounting parts
10.11.1 Type code
Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: H A S 1 0 . 1 - 0 0 1 - 0 0 2 - N N
① ② ③ ④ ⑤ ⑥
① Product:
HAS = IndraDrive accessories
② Series:
10 = Mechanical mounting parts
③ Design:
1 = 1
④
Device assignment
1)
:
001 = KSM01.2, KSM02.1 KMS01.2 and KMS02.1
002 = HMU05.1
⑤
Other properties
2)
:
001 = Fixing clip of connectors for increased vibration resistance
002 = Fixing clip of connectors and master communication for increased vibration resistance
003 = Blank cover for mounting bays: 1 × parallel module / 1 × motor mains module / 1 × control
section
004 = Motor monitor grounding
005 = Mounting plate for device width 200 mm
006 = Mounting plate for device width 220 mm
007 = Fixing clip for increased vibration resistance (maritime applications)
008 = 335 mm Cross bar (for HAS10.1-002-007-NN)
009 = 555 mm Cross bar (for HAS10.1-002-007-NN)
010 = 775 mm Cross bar (for HAS10.1-002-007-NN)
011 = 995 mm Cross bar (for HAS10.1-002-007-NN)
012 = Push-through technology frame, size 1
013 = Push-through technology frame, size 2
014 = Push-through technology frame, size 3
⑥ Other design:
NN = None
1) Device assignment "001" is only available with Other properties
"001" and "002".
2) Device assignment "002" is only available with Other properties
"003" to "011".
Tab. 10-12: HAS10, type code
320/407
Accessories
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
