9.6.3 Electrical interfaces
Overall connection diagram
At the first KSM/KMS, always plug the hybrid cable RKH in
connection point X103.1.
Always terminate the unassigned X103.x connections at
KSM/KMS/KMV with an RHS terminal connector so that the
degree of protection IP65 is maintained.
The figures below show examples. Other mains connection options are
described in the documentation "Rexroth IndraDrive Drive Systems with
HMV01/02, HMS01/02, HMD01, HCS02/03".
The additional components (DST, HNL, HNF …) contained in the figure are
not absolutely necessary. As regards the detailed configuration of a drive
system, see documentation "Rexroth IndraDrive Drive Systems with
HMV01/02, HMS01/02, HMD01, HCS02/03".
288/407
Mounting and installation
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
