5.9.3 Selecting RKH hybrid cable incl. communication
Use the table below to select an RKH hybrid cable for the appropriate
connection with different outgoing directions from connection point X103.1 or
X103.2.
Target
1)
2)
3)
X103.1 X103.1 X103.1 RKH0700 Circular
connector
Source
KCU02 RKH0311 RKH0411 RKH0511 RKH0511 RKH0903
HCS01
5)
RKH0341 RKH0441 RKH0541 RKH0541 RKH0909
1)
X103.2 RKH0011 RKH0111 RKH0213 RKH0213 RKH0901
2)
X103.2 RKH0110 RKH0210 RKH0215 RKH0215 RKH0904
3)
X103.2 RKH0212 RKH0214 RKH0610 RKH0610 RKH0906
RKH0700 RKH0212 RKH0214 RKH0610
-
4)
tbd
Circular
connector
RKH0902 RKH0905 RKH0907 tbd RKH0900
1) Outgoing direction "A"
2) Outgoing direction "B"
3) Outgoing direction "V"
4) To interconnect two RKH0700 cables, use a short RKH0610
cable as an intermediate piece
5) HCS01.1E-W0054 with HAS05.1-023 accessories
Tab. 5-21: RKH hybrid cable
