6.6.13 Connection cover: Mounting options
Fig. 6-18: Connection cover: Mounting options
Tightening torque of the mounting screws: 2.5 Nm
6.6.14 Two-piece connection cover
See chapter 14.3 "Two-piece connection cover" on page 374.
206/407
Connection points
IndraDrive Mi Drive Systems with KCU02, KSM02,
KMS02/03, KMV03, KNK03, KLC03
Bosch Rexroth AG R911335703_Edition 04
